Microprocessor
based Thermometer Model KRT 406 GSM
Printable version
of the leaflet.
Description
Microprocessor based THERMOMETER model KRT - 406 GSM
is a modern device designed to measure temperature even in four
different places and is also able to record measure result in
its internal, nonvolatile memory or print them on a portable printer PORTI
S30/40. Through RS-232 or RS-485 socket it can communicate with a PC computer.
RS-485 socket allows to connect up to 8 units of KRT - 406 GSM to only
one computer PC by a triple wire line.
Internal, nonvolatile, memory enable to record up to 50 000 records
at intervals ranging from 1 minute to 99 hours. Results recorded in the
internal memory might be transferred to th e computer PC directly connected
to the KRT - 406 GSM`s RS-232 output. In the field
operation, a portable, battery powered printer
can be directly connected to the KRT - 406 GSM thermometer. The
user can select chart or graphs printout using a thermohygrometer`s keyboard.
This sophisticated thermometer covers temperature range from -90oC
to +300oC with resolution
0.02oC.
Highier accuracies, grater than typical electronic thermometers are achieved
through a unique linearising technique.
Application of the internal microprocessor ensure a minimal measuring
error and a large alphanumeric easy-to read LCD display enable simply
read-out results. Nonvolatile memory stores setup conditions (RS-232,
log intervals, probes calibration etc) and also user's settings selected
from the keyboard. The meter also includes a real time clock which shows
time, day month and year. The meter accepts up to
four temperature probes with very long cables (up to
100 meters each).
The KRT -406 GSM features a quick disconnect panel input for all probes.
The model KRT - 406 GSM also contains visual alarms.
Simultaneous alarm points for temperature are user selectable. When the
current condition exceed any of the preset values, special icons on the
front panel lit.
This model also features the special port to connect the GSM modem
in order to sending the alarm SMSes
or current measurement results on even three mobile telephones
(on demand).
Easy routine maintance and small size provides an excellent comfort of
recording and wide application in scientific research, enviroment measurement,
food industry and many others.
Technical data:
Input : ................................................................
four or two Pt-100 temperature probes (4 wire)
Distance between probes and meter: ............................ up to
100 meters
Temperature probe calibration: ......................................
automatic matching at 0oC
Temperature measuring and logging range :...................................................
-90oC to +300oC
Resolution of current temperature : .................................................................
0,02oC
Accuracy of temperature measurement: .........................................................+
0,15 % of the range
Log interval: ........................ from 1 minute to 99 hours (programmable
through the meter`s keyboard)
Start/End of the logging: .......................................... through
the meter`s keyboard
Connection to PORTI S30/40 printer : ................ RS-232 port on the
KRT - 406 GSM housing
Communication with computer PC : .................... RS - 232 ( distance
to computer PC up to 4 meters)
industrial RS - 485 - special converter necessary - (distance from computer
PC up to 100 meters)
Temperature display: .......................................................
4 x 16 alphanumeric LCD display
Device status display: ........................................................
4 x 16 alphanumeric LCD display
Switching of measuring channels: ....................................
through meter`s keyboard
Data logging (programmable by the user):
1.storing in the nonvolatile, internal memory (up to 12 500 logs for each
channel) and further transferable to the PC and/or to the portable printer
with the time and date stamp as a chart or grahps
2.On-line output to the PC through RS-232 serial interface or RS-485 industrial
interface for further analysis, storage and hard copy printouts
Power: ....................................................................
9 V or 12V dc or 230 V ac through an adapter
Housing: ........................................................... black
plastic adapted to be hanged on a wall
Dimensions: .................................................L200 x H95
x D37 mm
Logging Thermometer
Model TKP - 801 MMC
Description
The microprocessor based, small in size thermometer model TKP - 801 MMC
is designed to precise measurement and recording temperature. Its easy
routine maintenance, small size and battery supply provides an excellent
comfort of recording and wide application in scientific research,
enviroment measurement, food industry hygiene safety, and many others.
The TKP - 801 MMC thermometer and logger is also equiped with internal
nonvolatile memory enabling to record up to 50 000 records at ranging
from 1 minute to 99 hours. Results recorded in the internal memory might
be transferred to the computer PC directly connected to the TKP - 801
MMC' s
RS - 232 output.
Also, internal memory can be copied on the Multi
Media Card (MMC) inserted directly to the TKP - 801 MMC housing.
Than the MMC can be read-out through a standard memory card reader connected
to the computer PC. In the field operation a portable, battery
powered printer can be directly connected to the TKP - 801 MMC
thermometer. The user can select chart or graphs printout using a thermometer's
keyboard. This sophisticated thermometer covers temperature range from
-90oC to +300oC
with resolution 0,02oC. Highier accuracies, grater than typical
electronic thermometers are achieved through a unique linearising technique.
Application of the internal microprocessor ensure a minimal measuring
error and a large alphanumeric easy-to-read LCD display enable simply
read-out of results. Nonvolatile memory stores setup condtions (RS-232,
log interval, probe calibration) and also user`s setting seleted from
the keyboard. The meter also includes a real time clock which shows time,
day, month and year. The meter accepts a 4 wire Pt - 100 probe, which
allows to apply probes with very long cable (up to 50 meters). The TKP
- 801 MMC features a quick disconnect panel input for a probe. During
the process of recording, the thermometer allows read-out with 0,02*C
resolution of the current temperature and also minimal and maximal values
that were in the measuring area between switching on and off the meter.
The TKP - 801 MMC also contains visual alarms. Simultaneous alarm points
for temperature and humidity are user selectable. When the current condition
exceed any of preset values, special icon on front panel lit. Another
icon lit when batteries are near to dead.The long term batteries life
is achieved by the user selectable period (never, 2 or 10 minutes) freezing
of the readings when the meter is not in use.
Technical data
Temperature sensor : .............................. Platinum Pt - 100
probe (4 wire)
Temperature range: ...................................................................
-90oC to +300oC
Resolution of current temperature: ....................................................................
0,02oC
Resolution of the min/max temperature : ...........................................................
0,02oC
Accuraccy of temperature measurement: ...........................................................
+ 0,12% of the range
Temperature display :.....................................................
4 x 16 alphanumeric LCD display
Temperature probe calibration: .................................. automatic
matching at 0oC
Log interval: ............................... from 1 minute to 99 hours
(programmable through the meter`s keybroad)
Start/End of the logging : ...................................through
the meter`s keyboard
Data logging:
- storing in the nonvolatile, internal memory and further transferable
to the PC directly or through the MMC memory card
and/or to the portable printer with the time and date stamp as a chart
of graphs
- on-line output to the PC through RS-232 serial interface for further
analysis, storage and hard copy printouts
Digital output: ......................................................
RS - 232 serial interface output
Internal memory: ........................... up to 50 000 records
Power:......................................................... 4 x 1,5
V batteries
Housing: ...............................................................
black plastic
Dimensions: ..........................................................
215 x 115 x 42 mm
Microprocessor
based ThermoHygrometer model THM 406 FL
Description
Microprocessor based THERMOHYGROMETER model THM-406 FL is a modern device
designed to measure temperature and relative humidity even in four
different places and is also able to record measure result in
its internal, nonvolatile memory or print them on a portable printer PORTI
S30/40. Through RS-232 or RS-485 socket it can communicate with a PC computer.
Rs-485 socket allows to connect up to 4 units of THM - 406 FL to only
one computer PC by a triple wire line. Internal, nonvolatile, memory enable
to record up to 50 000 records at intervals ranging from 1 minute to 99
hours. Results recorded in the internal memory might be transferred to
th e computer PC directly connected to the THM-406 FL's RS-232 output.
In the field operation, a portable, battery powered printer can
be directly connected to the THM-406 FL thermohygrometer. The
user can select chart or graphs printout using a thermohygrometer`s keyboard.
This sophisticated thermohygrometer covers temperature range from -25oC
to +60oC with resolution 0.02*C and
humidity range from 5%RH to to 95% RH with resolution 0.5%RH.
Highier accuracies, grater than typical electronic thermohygrometers are
achieved through a unique linearising technique.
Application of the internal microprocessor ensure a minimal measuring
error and a large alphanumeric easy-to read LCD display enable simply
read-out results. Nonvolatile memory stores setup conditions (RS-232,
log intervals, probes calibration etc) and also user`s settings selected
from the keyboard. The meter also includes a real time clock which shows
time, day month and year. The meter accepts up to
four integrated temperature and humidity probes with
very long cables (up to 50 meters each). The THM-406 FL features a quick
disconnect panel input for all probes. The model THM-406 FL also contains
visual alarms. Simultaneous alarm points for temperature and humidity
are user selectable. When the current condition exceed any of the preset
values, special icons on the front panel lit.
Easy routine maintance and small size provides an excellent comfort of
recording and wide application in scientific research, enviroment measurement,
food industry and many others.
Technical data:
Input : ........................................... four or two integrated
humidity and temperature probes
Distance between probes and meter: ............................ up to
50 meters
Temperature measuring and logging range :...................................................
25oC to +60oC
Relative humidity measuring and logging range: ......................................................
5 do 98%.
Resolution of current temperature and humidity: ..........................................
0,02oC/0,5%RH
Accuracy of temperature measurement: .........................................................+
0,15 % of the range
Accuracy of relative humidity measurements: ......................+3%RH
@ temperature of calibration point
Log interval: ............... from 1 minute to 99 hours (programmable
through the meter's keyboard)
Connection to PORTI S30/40 printer : ................ RS-232 port on the
THM-406 FL housing
Communication with computer PC : .................... RS - 232 ( distance
to computer PC up to 4 meters)
industrial RS - 485 - special converter necessary - (distance from computer
PC up to 100 meters)
Temperature and humidity display: ................................. 4
x 16 alphanumeric LCD display
Device status display: ........................................................
4 x 16 alphanumeric LCD display
Switching of measuring channels: ....................................
through meter`s keyboard
Data logging (programmable by the user):
1.storing in the nonvolatile, internal memory (up to 12 500 logs for each
channel) and further transferable to the PC and/or
to the portable printer with the time and date stamp as a chart or grahps
2.On-line output to the PC through RS-232 serial interface or RS-485 industrial
interface for further analysis, storage and hard copy printouts
Power: ......................................................................
9 V dc or 230 V ac through adapter
Housing: ............................................................
black plastic adapted to be hanged on a wall
Dimensions: .......................................................L200
x H95 x D37 mm
Microprocessor based ThermoHygrometer
model THM 201 L
Printable version of
the leaflet.
Description
The microprocessor based thermohygrometer model THM-201 L is ideal for
both on-site and field relative humidity and temperature readings. The
humidity sensor possesses long term stability and negliglible hysteresis.
Also, it is nsensitive to most chemical non-agresive vapours.
For measurements in dust enviroment you can choose a probe with the sintered
filter. The temperature channel in the THM-201 L thermohygrometer features
Pt - 100 probe for the accurate reading. This model of thermohygrometer
has a large easy-to-read LED display allowing 0.1*C and 0.5% RH resolution.
The sensitive sensor elements are formed into a single unit.
This combination probe, is plug-in directly to the meter or through the
cable, and measures humidity to 98% at temperature up to 60*C.
The probe allows to use very long cable (up to 50 meters). Nonvolatile
memory stores setup conditions (probe calibration). Higher accuracies,
greater than typical electronic thermohygrometers are achieved through
a unique linearising technique.
Application of the internal microprocessor ensure a minimal measuring
error and a large easy-to-read LED display enable simply read-out of results.
Easy routine maintance and small size provides an excellent comfort of
using and wide application in scientific research, enviroment measurements,
food industry and many others.
Technical data:
Humidity : ................................................... thin film
sensor
Temperature input: ..................................... Pt - 100 sensor
according to EN 60751+ A1: 1999
Range of temperature measuring : ................................ -25*C
do + 60*C
Range of humidity measuring: ....................................... 5%
do 98% RH
Temperature/humidity resolution: .................................. 0,1*C/0,5%
RH
Humidity accuracy: ............. + 3% for 20%<RH<90% ( at calibration
temperature) + 5% below 20% RH or above 90% RH
Temperature accuracy: ........................... + 0,4*C
Operating temperature :......................... ... +5*C do +40*C
Operating humidity:..................................... up to 85% RH
Distance between meter and probe : ......... up to 50 meters
LED brightness setting: .............................. knobs on meter
housing
Power : .............................................................
9 to 12 Volt, dc or 230 V ac trough an adapter
Housing: .....................................................................
black plastic
Size: ..........................................................................
L145 x W75 x D40 mm
Microprocessor Thermometer/logger TKP 202m
Description:
Microprocessor pocket thermometer TKP-202m is a hand meter designed to precize
measurment and recording temperature of constant bodies, liquids and gases. Its easy routine
maintance, small size and battery supply provides an excellent comfort of recording and wide
application in scientific research, ceramic industry, driers, textile, plastics and gum industry.
Microprocessor thermometer TKP-202m collaborates with Pt-100 probes. Application of internal
microprocessor ensure a minimal measuring error and a large alphanumeric easy-to-read LCD display
enables saving a battery. Unique advantage of a thermometer is a possibility of preprogrammed
matching temperature characteristic of a probe applied by User.
Also using a 4 line probe cable allows to apply probes with a long wire (up to several meters).
Thermometer allows a read-out of actual temperature and also a minimal and maximal temperature,
which were in measuring area between switching on and off the thermometer. It is also possible to
programm it by RS-232 socket from a computer, so it can record into its internal memory results of
measurment temperature in User marked time. After recording results of measurment gathered in
internal memory might be transferred into a computer’s hard disk.
Technical data
Temperature probe.......................................................... Platinium Pt-100 RTD
Way of connecting probe to thermometer........................ 4 wire line
Resolution of actual temperature..................................... 0.01
oC
Resolution of min/max temperature................................. 0.01 oC
Accurancy of temperature measure.......... 0.05% of measuring range -50 oC to +150
oC
0.1% of measuring range +150
oC to +200 oC
Temperature read-out....................................................... Alphanumeric LED display
Communication with a computer...................................... RS-232 socket (up to 3 m)
Internal memory (version FI)............................................ Up to 50000 readings
Microprocessor based Thermometer/Datalogger
KRT 102
Description:
Microprocessor based Geneza Ltd. Temperature logger KRT-102 is designed
to precize measurement and recording temperature in food, pharmaceutical
industry, fruits ripening tanks, cold stores (HACCP) and air conditioned
muzeums, banks and hospitals. Its easy maintance and small size provides
an excellent comfort of recording and wide application in scientific research
and also in industry conditions.
Microprocessor thermometer KRT 102 collaborates with Pt-100 probes, and
with a computer by RS-232 socket. Application of the internal microprocessor
ensure a minimal measuring error and a large alphanumeric easy-to-read
LCD display enables saving the battery. Unique advantage of the thermometer
is a possibility of reprogrammed matching temperature characteristic of
a probe applied by User. Also using a 4 line probe wire allows to apply
probes with very long conductor (up to 100 m) During the process of recording
the thermometer of the logger allows a read-out with 0.01oC
resolution of the actual temperature and also a minimal and maximal temperature,
which were in measuring area between switching on and off the logger.
Technical data:
Temperature probe.......................................................... Platinium Pt-100 RTD
Range for temperature measuring..................................
-60oC to +200oC
Range between a logger and a probe............................. Up to 100m (4 wire line)
Way of connecting probe to logger.................................. 4 wire
Resolution of actual temperature....................................
0.01oC
Resolution of min/max temperature................................
0.01oC
Accurancy of temperature measure................................
0.05o
Communication with a computer..................................... RS-232 socket (up to 3 m)
Log intervals.................................................................... from 1 minute to 99 hours
Archivization of results..................................................... computer hard disk
Temperature read-out...................................................... Alphanumeric LED display
Power.............................................................................. 220 V/9 V dc
Operating humidity ......................................................... Up to 85% RH
Housing ........................................ Black plastic, adapted to be hanged
on the wall
Microprocessor based Thermometer/Datalogger
KRT 2002
Description:
Microprocessor based Geneza Ltd. Temperature logger KRT 2002 id designed to precize mesurement
and recording temperature in food, pharmaceutical industry, fruits ripening tanks, cold stores (HACCP)
and air conditioned museums, banks and hospitals. Its easy toutine maintance and small size provides
an excellent comfort of recording and wide application in scientific research and also in
industry conditions. A device is equiped with internal battery backup during power failure, so even if external
power failured recording is being continued.The logger is also equiped with internal nonvolatile memory,
enabling recording up to 70000 records. Results recorded in internal memory might be transferred into
computer or printed on the computer printer directly connected to the KRT 2002 centronics parallel
printer output.
Computer temperature logger KRT-2002 collaborates with Pt-100 probes, and with a computer by
RS-232 or RS-485 socket. RS-485 socket allows to connect up to 32 units of KRT 2002 to only one
computer by a triple wire line.
Application of the internal microprocessor ensure a minimal measuring error and a large alphanumeric
easy-to-read LCD display enables simple read-out of results. Unique advantage of thermometer/logger is
a possibility of preprogrammed matching temperature characteristic of a probe applied by User.
Also using a 4 line probe wire allows to apply probes with very long cable (up to 100 m).
During the process of recording the thermometer of the logger allows a read-out with
0.01oC resolution of the actual temperature and also a minimal and maximal temperature, which were in measuring area
between switching on and off the logger.
Technical data
Temperature
probe................................................................ Platinium Pt-100 RTD
Range of temperature measuring...................................... -50oC to +160o C
Range between a logger and a probe................................. Up to 100 m (4 wire line)
Way of connecting probe to logger...................................... 4 wire
Resolution of actual temperature........................................ 0.01
oC
Accurancy of temperature measure............................... 0.05 oC of measuring range
Communication with a computer.. RS-232 socket (up to 3 m), RS-485 socket (up to
100 m)
Log intervals...................................................... From 15 sec. To 99 hours
Archivization of
results...................................................... Computer’s hard disk
Temperature read-out................................................ Alphanumeric LED display
Power.................................................................................. 220 V/ 9V dc
Operating
humidity............................................................... Up to 85% RH
Housing..................... Black plastic adapted to be hanged on a wall
Microprocessor based Thermohygrometer model THM 2001 GSM
Description:
Microprocessor based Thermohygrometer THM 2001 GSM is a modern device designed to measure temperature and
relative humidity and is also able to record measure results in its internal memory or print them on a printer. By RS-232
socket it can communicate with a computer.
A device has also a special socket to communicate with a GSM Modem, so it is able to send automatically alert
announcements as SMSes to up to six different mobile phones. There is also a possibility of sending a measure
results on demand. Meter is placed in severe conditions resistant housing meeting requirements of IP 65 norm, and
in supply system is integrated a special interference eliminator filter what enables a wider range of applying
THM 2001 GSM. Easy thermohygrometer maintance and simple wall-mount
provide a large measure or recording temperature and relative humidity comfort.
A device is specially designed for food, dairy and textile industry, fruits ripening tanks, driers,
fruit-and-vegetable processing, metereology, and air conditioned laboratories, museums and hospitals. Meter collaborates with Pt-100 probes and a unique
advantage of thermohygrometer is a possibility of preprogrammed matching temperature characteristic of
a probe applied by User. Thanks to this function it is possible to obtain a perfect measure even though using a C class probe.
Humidity measurment is done by thin film capacitance probe. In electronic system is applied a hybrid micromodule and a
preprogrammed matching temperature characteristic of relative humidity probe what ensure a perfect measure.
Setting of all measure parameters and alerts is possible thanks to keyboard placed on the front panel of a thermohygrometer.
Read-out of measure results and programmed parameters is feasible because of big backlit alphanumeric LCD display whats
enable a read-out in dark and light places.
Technical Data:
Temperature
sensor.............................................................Platinium Pt-100 class B
Relative humidity sensor.....................................Thin film capacitance probe
Range of temperature
measure.....................................................-25 to +60
Range of relative humidity
measure............................................ 5% to 95%
Resolution of temperature/humidity
measure................................... 0,1oC
Accurancy of temperature measure ................................ +0,1 % of measure range
Accurancy of relative humidity measure ....... + 5% in temperature calibration point
Calibration:
temperature: .............................. In two or three points selacted from a keyboard
relative humidity:
........................................ In two points selected from a keyboard
Log intervals: ....................................... From 1 minute up to 99
days (programmable)
Datalogging capabilities to internal memory......................................... 3000
Display read-out:............................ actual temperature and relative humidity or
on demand sending a SMS on User mobile phone.
Way of recording measure result... Internal memory or computer printer with EPSON 9 emulation
Way of connecting a computer printer.....................centronics socket on device’s
housing (up to 2 meters)
Communication wih a computer: .......................................... RS - 232 (up to 3 meters)
Communication with a GSM modem: ......................... Socket on a device’s housing
Way of printing: ......................................................... Charts and graphs
Alerts: ..................................... Sending a message on 1 to 6 different GSM numbers
Way of setting-up alerts:.............................................. ...... By a keyboard
Housing:.................................. .........astic, adapted to be hanged on the wall
Access to control keys: ........................................... Flipping open front panel door
Overall dimensions: ................................. L 275 x H 210 x D 140 mm
Microprocessor Thermometer Model TKK – 100
Description
The TKK - 100 is a high precision microprocessor controlled, pocket
size meter which accepts a K type (NiCr - NiAlSi) thermocouple. This model
features a quick disconnect panel jack input for sensor and a large easy -
to - read LCD display allowing 1oC resolution in the
temperature range from 0oC to +1250oC. Higher
accuracies, greater than for a typical electronic thermometer, are
achieved through a unique linearizing
technique.
The TKK - 100 is a compact, high precision thermometer with a K
thermocouple completely interchangeable through the connector base and
covers a broad range of applications, including laboratory, industrial and
warehouse, in food, grains and particles, in tank and narrow gaps, between
sheets of paper and cloth, in wall crevices, and for many applications in
pharmacy, plastic processing, foundry or factory enviroment.
Technical data - Version K
Input : .................................................. thermocouple
probe type K (NiCr - NiAlSi)
Probe calibration: ................................... automatic matching
by microprocessor at 0oC
Range:
..................................................................... 0oC
to +1250oC
Resolution:
............................................................... 1oC
Display:
.................................................................... 4
digit LCD
Operating ambient: ................... -10oC to +40oC;
40 to 80%RH, non-condensing
Internal battery:.........................................................
9 Volts
Housing:
.................................................................... black
plastic
Dimensions: .............................................................
118 x 74 x 28 mm
Microprocessor Thermometer Model TKP – 100
Description
The TKP - 100 is a high precision microprocessor controlled, pocket
size meter which accepts a Pt - 100 platinum resistive sensor. This model
features a quick disconnect panel jack input for sensor and a large easy -
to - read LCD display allowing 0.1oC resolution in the
temperature range from -200oC to +850oC. Higher
accuracies, greater than for a typical electronic thermometer, are
achieved through a unique linearizing
technique.
The TKP - 100 is a compact, high precision thermometer with a Pt - 100
probe completely interchangeable through the connector base and covers a
broad range of applications, including laboratory, industrial and
warehouse, in food, grains and particles, in tank and narrow gaps, between
sheets of paper and cloth, in wall crevices, and for many applications in
pharmacy, plastic processing, foundry or factory enviroment.
Technical data - Version P
Input :
......................................................................
platinum Pt - 100 probe
Probe calibration: ........................ automatic matching by
microprocessor at 0oC
Range:
..................................................................... -200oC
to +850oC
Resolution:
............................................................... 0.1oC
Display:
.................................................................... 4
digit LCD
Operating ambient: ............... -10oC to +40oC;
40 to 80%RH, non-condensing
Internal battery:.........................................................
9 Volts
Housing:
.................................................................... black
plastic
Dimensions: .............................................................
118 x 74 x 28 mm
High Precision Digital Thermometer Model TKE - 100
Description
The TKE - 100 is a high precision digital pocket size meter which
accepts a Pt - 100 platinum resistive sensor. This model features a quick
disconnect panel jack input for a probe and large easy - to - read LED
display allowing 0.1oC resolution in the temperature range from
- 200oC to +200oC. The TKE - 100 is a compact high
precision thermometer with a Pt - 100 probe completely interchangeable
through the connector base and covers a
broad range of applications, including laboratory and warehouse, in food,
grains and particles, in tanks and narrow gaps, between sheets of paper
and cloth, in wall crevices, and for many every day uses in an office or
factory enviroment.
Technical Data
Input
.................................................................................Platinum
Pt - 100 probe
Range
...............................................................................
-200oC to +200oC
Resolution
...........................................................................
0.1oC
Display
.................................................................................
31/2 Digit LED
Operating temperature
......................................................... +5oC
to +40oC
Power
............................................................................
internal battery 9 Volt
Housing
............................................................................
black plastic
Dimensions
...........................................................................
118 x 74 x 28 mm
Microcomputer Panel Thermometer Model TP - 196 Version
K
Description
The TP - 196 Version K is a high precision microcomputer controlled,
DIN size meter which accepts a K type ( NiCr - NiAlSi ) thermocouple. This
model features a quick disconnect panel input for sensor and a large easy
- to - read LED display allowing 1oC resolution in the
temperature range from 0oC to+1250OC.
Higher accuracies, greater than typical electronic thermometer, are
achieved through a unique linearizing technique. The TP - 196 is a
compact, high precision thermometer with a K type thermocouple probe
completely interchangeable through the connector base and covers a broad
range of applications, including laboratory, industrial and warehouse, in
food, grains and particles, in tank and narrow gaps, between sheets of
paper and cloth, in wall crevices, and for many applications in pharmacy,
plastic processing, foundry or factory enviroment.
Technical Data
Input ............................................. thermocouple probe
type K ( NiCr - NiAlSi )
Range
...................................................................... 0oC
to +1250oC
Probe calibration ................................ automatic matching by
microcomputer at 0oC
Resolution
................................................................ 1oC
Display ................................................................ 4
digit LED (0.56 inch)
Operating ambient ................... -10oC to +40oC;
40 to 80% RH, non-condensing
Power
.......................................................................
220 Volts, 50 Hz
Housing
.....................................................................
black plastic
Dimensions ...............................................................
96 x 48 x 115 mm
Microcomputer Panel Thermometer Model TP - 196 Version P
Description
The TP - 196 Version P is a high precision microcomputer controlled,
DIN size meter which accepts a Pt - 100 platinum resistive sensor. This
model features a quick disconnect panel input for sensor and a large easy
- to - read LED display allowing 0.1oC resolution in the
temperature range from -200oC to+850OC.
Higher accuracies, greater than typical electronic thermometer, are
achieved through a unique linearizing technique. The TP - 196 is a
compact, high precision thermometer with a Pt - 100 probe completely
interchangeable through the connector base and covers a broad range of
applications, including laboratory, industrial and warehouse, in food,
grains and particles, in tank and narrow gaps, between sheets of paper and
cloth, in wall crevices, and for many applications in pharmacy, plastic
processing, foundry or factory enviroment.
Technical Data
Input
..............................................................................
Platinum Pt - 100 probe
Range
............................................................................
- 200oC to +850oC
Probe calibration .................................. automatic matching by
microcomputer at 0oC
Resolution
..................................................................... 0.1oC
Display
..........................................................................
4 digit LED (0.56 inch)
Operating ambient ............................ -10oC to +40oC;
40 to 80% RH, non-condensing
Power
............................................................................
220 Volts, 50 Hz
Housing
.........................................................................
black plastic
Dimensions
................................................................... 96 x
48 x 115 mm
Microcomputer Panel Thermometer Model TP - 196 Version
S
Description
The TP - 196 Version S is a high precision microcomputer controlled,
DIN size meter which accepts a S type (PtRh - Pt) thermocouple. This model features a quick disconnect panel
input for sensor and a large easy - to - read LED display allowing 1oC
resolution in the temperature range from 0oC to+1750OC.
Higher accuracies, greater than typical electronic thermometer, are
achieved through a unique linearizing technique. The TP - 196 is a
compact, high precision thermometer with a S type thermocouple probe
completely interchangeable through the connector base and covers a broad
range of applications, including laboratory,
industrial and warehouse, in food, grains and particles, in tank and
narrow gaps, between sheets of paper and cloth, in wall crevices, and for
many applications in pharmacy, plastic processing, foundry or factory
enviroment.
Technical Data
Input .............................................................
thermocouple probe type S ( PtRh - Pt )
Range
...................................................................... 0oC
to +1750oC
Probe calibration ................................. automatic matching by
microcomputer at 0oC
Resolution
................................................................ 1oC
Display
...................................................................... 4
digit LED (0.56 inch)
Operating ambient ..................... -10oC to +40oC;
40 to 80% RH, non-condensing
Power
.......................................................................
220 Volts, 50 Hz
Housing
.....................................................................
black plastic
Dimensions ...............................................................
96 x 48 x 115 mm
Microprocessor Thermohygrometer
Model THM 298
Description
Microprocessor based thermohigrometer model
THM 298 sets a new standards in thermohygrography. This temperature/relative
humidity datalogger accurately measures, indicate and record temperature and
relative humidity creating charts and graphs on the printer connected to its
parallel output. The instrument features backlit alphanumeric display and
battery backup during power failure. Model THM 298 also contains two relays
which switch contacts in response to an alarm condition. Simultaneous alarm
points for temperature and relative humidity are user selectable. When the
current condition exceed any of the
preset values the contacts of the relays switches and/or special icons on
the front panel lit.
This sophisticated wall-mount unit is assembled in rugged plastic housing
with flipping open front panel door which permits access to the control keys
of the thermohygrometer.
Technical data
Temperature sensor ......................................................
Platinum Pt - 100 RTD
Humidity sensor
................................................................... Thin
film capacitance
Range for temperature measuring ..................... -40oC to
+80oC (up to +120oC optionally)
Range of humidity measuring ................................................
5.0% to 100.0%
Temperature/humidity resolution
..................................................... 0.1oC/0.1%RH
Temperature accuraccy .................................................... +
0.1% of the range
Humidity accuraccy ............. + 2% @ calibration temperature, between 20
and 90% RH
.......................................+
5% @ calibration temperature, below 20% or above 90% RH
Instrument calibraton:
temperature .................... in one, two or three user selectable points
relative humidity .............. in one or two user selectable points
Log intervals ..................... from 1 minute to 99 hours (programmable)
Datalogging capabilities to internal memory .......................... up to
1000 readings
Datalogging:
- hard copy with the time and date on the printer connected to the
Centronics parallel printer output (charts)
- storing in the internal memory and further printing on the printer with
the time and date ( charts or graphs)
- output to the PC through RS - 232 serial interface for further analysis,
storage and hard copy printouts
Digital outputs:
RS - 232 serial interface
Centronics parallel printer output
Power
....................................................................................
220 V, AC
Housing ......................................... Wall-mount, easy-to-view,
IP 54 plastic housing
Dimension ................................................... 195 W x 210 H
x 140 D mm
Other unique features make the THM 298 an even better value: digital
calibration of both temperature and humidity channels with the code lock to
prevent unauthorized changing and minimum, average and maximum starage in
user selectable time interval. Nonvolatile memory stores setup conditions
(RS 232, printers, log start time, log interval, probe calibration, etc).
Microprocessor based temperature dataloggers Model KRT - 198
Geneza Ltd. 8-channel scanning
thermometers/loggers are perfect for simultaneous temperature monitoring during different
industrial and laboratory process steps.
Wall mount units in rugged plastic housing, which fulfil IP54 requirements, store data and
download to your PC or printer, because they feature RS 232 and Centronics parallel
printer output. Dependently from the model, this sophisticated thermometer covers
temperature range from -100oC to +1750oC
and achieve accuracies of +0.2% of reading. Reading may be logged and stored at
intervals ranging from 2 minutes to 99 hours. Nonvolatile memory stores setup conditions
(RS-232, printers, log interval, probe calibration). The meter also includes a real time
clock which shows time, day, month and year.
Higher accuracies, grater than the typical electronics HACCP, thermometers, are achieved through
a unique linearising technique. All models features a quick disconnect panel input
for probes and a large easy-to-read LED display allowing 0.1oC resolution for
Pt-100 probes and 1oC for thermocouples. However, if the meter is connected to
the PC you can achieve 0.01oC of resolution.
Common parameters:
Temperature display: ..................... 4 digit, red LED, 0.8 inch
Status display: ................................ 2 digit, green LED, 0.4
inch
Probe calibration: ........................... automatic matching at 0oC
Number of inputs: ........................... eight
Log interval: .................................... from 2 minutes to 99
hours (programmable)
Data logging:
- hard copy with the time and date on the printer connected to the
Centronics parallel printer output
- storing in the internal memory and further printing with the time and date
- output to the PC through RS - 232 serial interface for further analysis,
storage and hard copy printouts
Digital outputs: ................ RS - 232 serial interface and
Centronics parallel printer output
Power: ............................... 220 Volt, ac
Housing : .......................... wall mount, easy-to-view, drip proof
plastic housing
Model KRT - 198 version P
Temperature range: .................................................
-100oC
to +800oC
Resolution: ..............................................................
0.1oC
Input : .................................................... platinum
Pt-100 probe (2 or 4 wire)
Model KRT - 198 version J
Temperature range : ............................................
0oC
to +750oC
Resolution: ............................................................ 1oC
Input : ....................................................................
Thermocouple type J
Model KRT - 198 version K
Temperature range : ............................................ 0oC
to 1250oC
Resolution : .......................................................... 1oC
Input : .....................................................
Thermocouple type K
Model KRT - 198 version S
Temperature range: .............................................
0oC to 1750oC
Resolution: .......................................................... 1oC
Input : ...................................................................
Thermocouple type S
Digital, panel mount, thermohigrometer Model THC - 199
Description:
The THC - 100 is an unique dual display high precision panel mount, DIN sized,
meter for
simultaneous indication of both temperature and relative humidity. This
meter has broad applications in air conditioning services, food managements,
process engineering and many uses in experimental and research facilities.
The THC - 100 meter has large 0.8“ ( 2 cm) easy - to - read green LED
display for humidity reading and red display for temperature reading with
resolution 0.1% RH and 0.1oC respectively.
The sensitive sensor elements are formed into a single unit. This
combination probe measures humidity to 95% at temperatures up to 80oC.
Humidity range : ................................................ 5.0% to
99.0%
Temperature range : ..........................................
-20oC to +80oC
Temperature sensor : ....................................... Pt - 100 RTD
Humidity sensor : ............................................. thin film
capacitance
Humidity/Temperature resolution : ................ 0.1%/ 0.1oC
Humidity display : ............................................ 3 1/2 digit
green LED 0.4 inch large
Temperature display : ...................................... 3 1/2 digit red
LED 0.4 inch large
Temperature accuracy : .................................. + 0.5oC
Humidity accuracy : ........................................ + 5% @
25oC
Operating temperature : ................................. +5oC to
40oC
Operating humidity : ...................................... Up to 85%
Power : ............................................................ 220
Volt, ac
Housing : ......................................................... 96 x 96
x 110 mm (DIN size)
Microprocessor Based
Thermometer/Datalogger Model TKP-302 Fl
Description
Geneza Ltd. TKP-302FL thermometer/loggers are perfect for temperature monitoring during carriage of
food products. The cap mount units in rugged plastic housing, store data and
download to your PC , because the feature RS-232 output. The TKP-302FL logger is also
equipped with internal nonvolatile memory enabling recording up to 50 000 records at intervals ranging from 1 minute to 99
hours. Results recorded in internal memory might be transferred into computer directly connected to the
TKP-302FL`s RS-232 output. This sophisticated thermometer Covers temperature range from
-50oC to +200oC and achieve accuracy of + 0,1% of reading.
Nonvolatile memory stores setup conditions (RS-232, log interval, probe
calibration). The meter also includes a real time clock which shows time,
day, month and year.
Higher accuracy, grater than the typical electronic HACCP
thermometers are achieved through a unique linearising technique. Application
of the internal microprocessor ensure a minimal measuring error and
a large alphanumeric easy-to-read LCD display enable simply read-out of
results. The meter accepts a 4 wire Pt-100 probe, which allows
to apply probes with very long cable (up to 100 meters).
TKP-302FL features a quick disconnect panel input for a probe. During
the process of recording, the thermometer of the logger allows read-out
with 0.01oC resolution of the current temperature and also minimal and
maximal temperatures, which were in measuring area between switching on
and off the meter.
Technical data
Input: ........................................................................
Platinum Pt-100 probe (4 wire)
Temperature range: ...................................................................
-50oC to +200oC
Distance between a logger and the probe : ..............................
Up to 100 meters
Resolution of the current temperature: .....................................
0,01oC
Resolution of the min/max temperature: ...................................
0,01oC
Accuracy of temperature measurement: ...................................
0,1% of the range
Temperature display: ............................................ 4 x
16 alphanumeric LCD display
Probe calibration: ..................................................
Automatic matching at 0oC
Log interval: ................................... from 1 minutes to 99
hours (programmable)
Data logging:
- storing in the internal memory and further transferable to the computer
with the time and date as a chart of graphs
- output to the PC through RS - 232 serial interface for further analysis,
storage and hard copy printouts
Digital outputs:............................................. RS-232 serial
interface output
Internal memory: ..................................................up
to 50 000 records
Power: ....................................................................
12 Volts dc
Housing: ...............black plastic housing adapted to be hang in the
cap of the truck
Microprocessor Based Thermometer/Datalogger
Model TKP- 402Fl
Description
The microprocessor based, pocket size thermometer model TKP-402 FL (photo)
is designed to precise measurement and recording temperature. Its easy
routine maintenance, small size and battery supply provides an excellent
comfort of ecording and wide application in scientific research, enviroment
measurement, food industry and many others.
The TKP - 402FL logger is also equiped with internal nonvolatile memory
enabling to record up to 50 000 records at intervals ranging from 1 minute
to 99 hours. Results recorded in the internal memory might be transferred
to the computer PC directly connected to the TKP - 402FL's RS-232 output.
In the field operation a portable, battery powered printer can be directly
connected to the TKP - 402FL thermometer. The user can select chart
or graphs printout using a thermometer's keyboard.
This sophisticated thermometer covers temperature range from
-60oC to +200oC
with resolution 0,01oC and achieve accuracies +0,05%
of the range. Highier accuracies, grater than typical electronic thermometers
are achieved through a unique linearising technique.
Application of the internal microprocessor ensure a minimal measuring
error and a large alphanumeric easy-to-read LCD display enable simply
read-out of results. Nonvolatile memory stores setup condtions (RS-232,
log interval, probe calibration) and also user`s setting selected from
the keyboard. The meter also includes a real time clock which shows
time, day, month and year.
The meter accepts a 4 wire Pt - 100 probe, which allows to apply probes
with very long cable (up to 10 meters). The TKP - 402FL features a quick
disconnect panel input for a probe. During the process of recording, the
thermometer of the logger allows read-out with 0,01oC resolution
of the current temperature and also minimal and maximal temperatures that
were in measuring area between switching on and off the meter.
Technical data
Input: ...........................................................................
Platinum Pt - 100 probe (4 wire)
Temperature range: ......................................................
-60oC to +200oC
Resolution of current temperature: ..................................
0,01oC
Resolution of the min/max temperature: .......................... 0,01oC
Accuracy of temperature measurement: ....................... + 0,05%
of the range
Temperature display:.....................................................
4 x 16 alphanumeric LCD display
Probe calibration: .......................................................
automatic matching at 0oC
Log interval: ........................ from 1 minute to 99 hours (programmable
through the meter's keyboard)
Start/End of the logging: .............................................through
the meter's keyboard
Data logging:
- storing in the nonvolatile, internal memory and further transferable
to the PC and/or to the portable printer with the time and date stamp
as a chart of graphs
- on-line output to the PC through RS-232 serial interface for further
analysis, storage and hard copy printouts
Digital output: ..............................................................
RS - 232 serial interface output
Internal memory: .........................................................
up to 50 000 records
Power:........................................................................
4 x 1,5 V batteries
Housing: ....................................................................
black plastic
Dimensions: ...............................................................
146 x 82 x 39 mm
Microprocessor Based Thermometer/Datalogger
Model KRT-2004
Description
The microprocessor based thermometer/logger model KRT-2004 (photo)
is designed to precise measurement and recording temperature.
Its easy routine maintenance and small size provides an excellent comfort
of recording and wide application in scientific research, enviroment measurement,
food industry, pharmaceutical industry and many others.
The KRT-2004 logger is also equiped with internal nonvolatile memory enabling
to record up to 50 000 records at intervals ranging from 1 minute to 99
hours. Results recorded in the internal memory might be transferred to
the computer PC or to the special memory reader model
UC-103 directly connected to the KRT-2004 logger's RS-232 output.
The KRT-2004 is perfect for temperature monitoring during carriage of
food products. The cap mount unit
in
rugged plastic housing store data and download to your PC. In the field
operation a portable, battery powered printer can be directly
connected to the KRT-2004 RS-232 output. The user can select
chart or or graphs printout using a thermometer's keyboard.
This sophisticated thermometer covers temperature range from -60oC
to +200oC with resolution 0,01oC
and
achieve accuracies + 0,05% of the range. Highier
accuracies, grater than typical electronic thermometers are achieved through
a unique linearising technique.
Application of the internal microprocessor ensure a minimal measuring
error and a large alphanumeric easy-to-read LCD display enables simply
read-out of results. Nonvolatile memory stores setup conditions (RS-232,
log interval, probe calibration) and also user's settings selected from
the keyboard. The meter also includes a real time clock which shows
time, day, month and a year.
The meter accepts a 4 wire Pt-100 probe, which allows to apply probes
with very long cable (up to 50meters).
The KRT-2004 features a quick disconnect panel input for a probe.
During the process of recording, the thermometer of the logger allows
read-out with 0,01oC resolution of
the current temperature and also minimal and maximal themperatures that
were in measuring area between switching on and off the meter.
Model KRT-2004 also contains two coloured LEDs, which lit in response
to an alarm condition. Alarm
points for high (red LED) and low (green LED) temperatures are user selectable.
When the current condition exceed any of the preset values special icons
on the front panel lit.
Technical data
Input: ......................................................................
Platinum Pt - 100 probe (4 wire)
Temperature range: .......................................................................
-60oC to +200oC
Resolution of current temperature: ....................................................................
0,01oC
Resolution of the min/max temperature: ...........................................................
0,01oC
Accuraccy of temperature measurement:.......................................................
+ 0,05% of the range
Temperature display:.......................................................................
4 x 16 alphanumeric LCD display
Probe calibration: ......................................................
automatic matching at 0oC
Log interval: ............................... from 1 minute to 99 hours
(programmable through the meter's keybroad)
Start/End of the logging: ............................................through
the meter's keyboard
Data logging:
- storing in the nonvolatile, internal memory and further transferable
to the PC and/or to the portable printer with the time and date stamp
as a chart of graphs
- on-line output to the PC through RS-232 serial interface for further
analysis, storage and hard copy printouts
Digital output: .........................................................
RS - 232 serial interface output
Internal memory: ...................................................................
up to 50 000 records
Alarms (programmable)...........................................................
green/red LEDs
Power:.............................................. 12Vdc or 220Vac through
an adaptor
Housing: .............................................................
black plastic
Dimension: ................................................................
165 x 95 x 40 mm
|| Main Page || Company
Profile || Offer || Products || Cooperation offer
|| Validation || Email ||
Leaflets/specifications: Hygromethers,
Thermometers (Dataloggers), Calibrators, Memory
readers Temperature Probes, Humidity & temperature probes, Manometers,
Temperature Loggers
Copyright © 1999-2004 PW Geneza Ltd. All rights reserved.
|
